| Product Attribute | Attribute Value |
|---|---|
| Part Number | N0465WN140 |
| Manufacturer | IXYS / Littelfuse |
| Voltage - On State (Vtm) (Max) | 2.09 V |
| Voltage - Off State | 1.4 kV |
| Voltage - Gate Trigger (Vgt) (Max) | 2.5 V |
| Supplier Device Package | W90 |
| Series | - |
| SCR Type | Standard Recovery |
| Package / Case | TO-200AB, B-PuK |
| Package | Box |
| Operating Temperature | -60°C ~ 125°C |
| Mounting Type | Chassis Mount |
| Current - On State (It (RMS)) (Max) | 920 A |
| Current - On State (It (AV)) (Max) | 465 A |
| Current - Off State (Max) | 50 mA |
| Current - Non Rep. Surge 50, 60Hz (Itsm) | 5000A @ 50Hz |
| Current - Hold (Ih) (Max) | 250 mA |
| Current - Gate Trigger (Igt) (Max) | 250 mA |
| Base Product Number | N0465 |
